Dimension (HxWxD) mm | 96x96x40 |
Panel Cutout (mm) | 92×92 |
Display Size | Upper: 0.8 inch, Lower: 0.56 inch |
Display Type | 7 Segment LED, 4 Digit |
Rated Input | CT Secondary 5A (50 mA to 5A) CT Primary 5A to 6000A (Field Selectable) |
Output | Relay 1: 1 C/O 5A for Resistive Load |
Tripping Facility | High Alarm, Low Alarm |
Accuracy | Class 1.0 |
Power Supply | 100 to 270 VAC, 50/60 Hz |
CR 912
1Ø Current Controller
